Adjacent drip edge pieces should be lapped minimum 2 inches. Asphalt shingles should overhang the exterior edge of the drip edge by ¼ to ¾-inch.

Does drip edge overlap gutter?

The face of the drip edge should be overlapping the gutter so that no water is going in between the gutter and fascia and possibly rotting out the fascia that's holding the gutter up.

Should there be a gap between drip edge and fascia?

The best installation method is to leave a gap between the drip edge and the fascia board, about the width of a finger. The shingles should also overhang the drip edge 3⁄8 to 1/2 an inch.

How far should shingles overhang drip edge?

Shingles should not extend more than 3/4” (19 mm) past the drip edge. If shingles overhang the edge of the roof by more than 3/4” (19 mm), then they are not supported and may crack and break off.

Should I paint my drip edge?

The drip edge in and of itself is designed to protect the integrity of your roof, but that doesn't mean it doesn't also need its own protecting! Priming and painting will deliver that protection, along with a cohesive aesthetic if your drip edge is visible.

How To Install Drip Edge On A Roof

33 related questions found

Does drip edge go over or under felt?

Does Drip Edge Go Over or Under Felt? According to most building codes and manufacturer recommendations, the drip edge should be installed beneath the underlayment along the eaves of the roof.

Should I overlap flashing?

Flashing should overlap the roof-covering material, but on asphalt shingle roofs, for aesthetic reasons, the part of the headwall flashing that extends down over asphalt shingles is often covered with a course of shingle tabs. ... Wind-driven rain can enter at these gaps, causing roof leaks.

How much should you overlap flashing?

Place each step flashing piece about ¼ inch short of the bottom edge of the shingle that will overlap it — just enough so that the flashing piece is not visible when the overlapping shingle is in place.

Can you install drip edge after shingles?

Can Drip Edge Be Installed After Shingles? The most popular time to install a drip edge is when new shingles are installed. However, the drip edge can be installed at any time. The materials involved include: a ladder, a flat pry bar, a hammer, tin snips, eave stripping, and galvanized roofing nails.

What color drip edge should I choose?

If your home's trim and fascia are white, it is recommended you select a white drip edge for seamless blending of elements throughout. If your home has more pops of brown, similar to the home displayed in the photo to the right, you may want to choose a brown drip edge.

Is drip edge visible?

The drip edge should be visible without having to lift the shingles. It will look like a thin strip of trim across the top of the gutter. If you can't see any drip edge hanging from under the shingles then it is probably missing. However somebody may have installed it wrong or cut it wrong to where you can't see it.

How do you paint under drip edge?

Paint or metal? If they install the aluminum fascia cover, it will slip under the drip edge break and essentially make it waterproof. If you choose to paint it, simply use a 4" wallboard knife to lift the drip edge up and away as you brush paint under it. The raw wood under the drip edge will last a long, long time.

What is the difference between drip edge and gutter apron?

A drip edge, which is installed along the eaves and roof edge, directs the water away from your fascia board and into the gutter. On the other hand, a gutter apron has the advantage of providing you with less maintenance over time. Gutter flashing or gutter apron serves the primary purpose of collecting all the water.

Should gutters be flush against fascia?

Should Gutters Be Flush With Fascia Boards? Gutters are installed on the face of the fascia boards. It is recommended to lay down a protective piece of furrier strip rather than leaving them flush. This is because fascia will be exposed to a lot of dark and dampness.

Does drip edge go above tar paper?

The drip edge should be over the paper at the eaves, and under along the rake. cwalsh: The drip edge should be over the paper at the eaves, and under along the rake.

Can you bend drip edge?

Two people can bend and install drip edge faster and easier. A drip edge is a strip of flashing material which is nailed along the edge of the roof to prevent water from getting under the roofing material.

Why is water dripping between gutter and fascia?

If water is dripping behind your gutter, it's probably because it was installed without any flashing over the back of the gutter. The gutter apron will prevent the dripping. A gutter apron is a bent piece of flashing that tucks up under the shingles and over the gutter. Home centers sell a gutter apron in 10-ft.

How much should a starter overhang for shingles?

Starter shingles should always overhang the eave and rake edges of the roof by about 1/4"-3/4" to ensure adequate rain water drainage. It is also important that the seal strip is placed facing up and close to the edge of your roof; otherwise, your roofing system won't seal properly.
